Online Access Free F5.301b.v2022-02-23.q185 Practice Test (Page 8)

301b Exam Question 31

An LTM device pair is configured for failover and connection mirroring. The LTM devices are configured with virtual servers for HTTP, HTTPS with SSL offload, and SSH. An event occurs that causes a failover. HTTP and SSH sessions active at the time of failover remain active, but HTTPS sessions are dropped.
What is the root cause of this problem?

A.Connection mirroring is incompatible with clientssl profiles.

B.Connection mirroring was NOT enabled for the HTTPS virtual servers.

C.SNAT automap was NOT enabled for the HTTPS virtual servers.

D.The SSL certificates on the LTM devices do NOT match.

301b Exam Question 32

An LTM Specialist is troubleshooting an HTTP monitor. The pool member is accessible directly through a browser, but the HTTP monitor is marking the pool member as down.
GET / HTTP/1.1
HTTP/1.1 400 Bad Request
DatE. Tue, 23 Oct 2012 21:39:07 GTM
Server: Apache/2.2.22 (FreeBSD) PHP/5.4.4
mod_ssl/2.2.22 OpenSSL/0.9.8q DAV/2
Content-LengtH. 226
Connection: close
Content-TypE. text/html; charset=iso-8859-1
Which issue is the pool member having?

A.The pool member is NOT accepting requests from the LTM device IP address.

B.The pool member lacks the object requested by the monitor.

C.The pool member has too many concurrent connections.

D.The pool member is rejecting the request because it is invalid.

301b Exam Question 33

-- Exhibit-

-- Exhibit -
Refer to the exhibits.
How should the LTM Specialist minimize the configuration?

A.Create a single monitor, apply it to the pool, and remove the pool member level monitors.

B.Remove the pool member level monitors.

C.The configuration is as minimized as possible.

D.Create a single monitor and apply it to each pool member.

301b Exam Question 34

What is the recommended procedure for upgrading a major TMOS release on a BIG-IP platform?

A.1. Take a configuration backup.
2.Reboot the device to the non-active volume.
3.Renew the device license.
4.Upload the device code.
5. Install device code to the current volume.

B.1. Take a configuration backup.
2.Upload the device code.
3.Install device code to the non-active volume.
4.Reboot the device to the non-active volume.
5.Renew the device license.

C.1. Renew the device license.
2.Take a configuration backup.
3.Upload the device code.
4.Install device code to the non-active volume.
5.Reboot the device to the non-active volume.

D.1. Renew the device license.
2.Take a configuration backup.
3.Reboot the device to the non-active volume.
4.Upload the device code.
5.Install device code to the current volume.

301b Exam Question 35

An LTM device is serving an FTP virtual server that has three pool members. The FTP pool members are monitored via TCP port 21. Customers are reporting that they are able to log in, but are sometimes unable to upload files to the server.
Which monitor should the LTM Specialist configure to verify that the servers can handle file uploads?

A.Real Server

B.External

C.Scripted

D.FTP

E.Inband
