The exhibit shows an active-passive HA (high availability) cluster with two virtual clusters, where FortiGate_A is the primary device for both Core1 and Core2. If the goal is to have FortiGate_B take over Core2 traffic, its priority must be higher than FortiGate_A for Virtual Cluster 2.
Currently, FortiGate_A has a priority of 150 for Core2, while FortiGate_B has 128. Increasing FortiGate_B's priority to 200 ensures it becomes the primary for Virtual Cluster 2, taking over the Core2 VDOM traffic while keeping Core1 traffic on FortiGate_A.
Disabling override would prevent forced failovers but wouldn't change the role distribution. Adjusting the load-balancing method is irrelevant in an active-passive setup, as it only applies to active-active configurations.

In ADVPN (Auto-Discovery VPN) configurations, security concerns include protecting peer IDs during VPN establishment. Peer IDs are exchanged in the IKE (Internet Key Exchange) negotiation phase, and their exposure could lead to privacy risks or targeted attacks.
# IKEv2 encrypts peer IDs, making it more secure compared to IKEv1, where peer IDs can be exposed in plaintext in aggressive mode.
# IKEv2 also provides better performance and flexibility while supporting dynamic tunnel establishment in ADVPN.

The packet capture output displays a TLS Client Hello message from FortiGate to FortiManager Cloud. This message contains Server Name Indication (SNI), which is used to indicate the domain name that FortiGate is trying to connect to.
FortiGate will receive a certificate that supports multiple domains because FortiManager operates in a cloud computing environment.
# FortiManager Cloud hosts multiple customers and domains under a shared infrastructure.
# The TLS handshake includes SNI (Server Name Indication), which allows FortiManager Cloud to serve multiple certificates based on the requested domain.
# This means FortiGate will likely receive a multi-domain or wildcard certificate that can be used for multiple customers under FortiManager Cloud.
The wildcard for the domain .fortinet-ca2.support.fortinet.com must be supported by FortiManager Cloud.
# The SNI extension contains the domain 9398.support.fortinet-ca2.fortinet.com.
# FortiManager Cloud must support wildcard certificates such as *.fortinet-ca2.support.fortinet.com to securely manage multiple subdomains and customers.
# This ensures that FortiGate can validate the server certificate without any TLS errors.

The excessive DNS log requests with random subdomains suggest a DNS exfiltration attack, where attackers encode and transmit data via DNS queries. Since this technique can use both UDP and TLS (DoH - DNS over HTTPS), a comprehensive security approach is needed.
Using an IPS profile with DNS exfiltration-specific signatures allows FortiGate to:
# Detect and block abnormal DNS query patterns often used in exfiltration.
# Inspect encrypted DNS (DoH, DoT) traffic if SSL inspection is enabled.
# Identify known exfiltration domains and techniques based on FortiGuard threat intelligence.

This IPsec Phase 1 configuration defines a dynamic VPN tunnel that can accept connections from multiple peers. The settings chosen here suggest a configuration optimized for networks with intermittent traffic patterns while ensuring resources are used efficiently.
Key configurations and their impact:
# set type dynamic # This allows multiple peers to establish connections dynamically without needing predefined IP addresses.
# set ike-version 2 # Uses IKEv2, which is more efficient and supports features like EAP authentication and reduced rekeying overhead.
# set dpd on-idle # Dead Peer Detection (DPD) is triggered only when the tunnel is idle, reducing unnecessary keep-alive packets and improving resource utilization.
# set add-route enable # FortiGate automatically adds the route to the routing table when the tunnel is established, ensuring connectivity when needed.
# set proposal aes128-sha256 aes256-sha256 # Uses strong encryption and hashing algorithms, ensuring a secure connection.
# set keylife 28800 # Sets a longer key lifetime (8 hours), reducing the frequency of rekeying, which is beneficial for stable connections.
Because DPD is set to on-idle, the tunnel will not constantly send keep-alive messages but will still ensure connectivity when traffic is detected. This makes the configuration ideal for networks with regular but non- continuous traffic, balancing security and resource efficiency.
