An RF plan specifies wide sector directional antennas.
Refer to the antenna specifications.
H-plane refers to the Azimuth or Horizontal plane and E-plane refers to Elevation or Vertical plane.
Antenna 1: H-plane = 360; E-plane = 120
Antenna 2: H-plane = 360; E-plane = 60
Antenna 3: H-plane = 100; E-plane = 90
Antenna 4: H-plane = 60; E-plane = 60
Which antenna specifications indicate that the antenna is a good choice for the plan?

Refer to the exhibit.

An architect selects 5406R switches for the aggregation layer. What is an appropriate amount of bandwidth for the link aggregation between each aggregation layer VSF fabric and the campus core?

An architect needs to plan an 802.11ac upgrade for an office building. The customer has requested an active survey. Which approach should the architect take to determine the cell edges?

Read this scenario thoroughly, and then answer each question that displays on the right side of the screen.
An architect proposes these products for a customer who wants a wireless and wired upgrade:
Aruba 2930M switches at the access layer
Aruba 5406R switches at the core
Aruba AP-325s
Aruba 7205 Mobility Controllers (MCs), deployed in a cluster
Aruba Mobility Master (MM)
Aruba ClearPass Cx000V
Aruba AirWare
The architect also needs to propose a security plan for the solution. The customer has 900 employees and up to
30 guests a day. The customer wants to protect the internal perimeter of the network with authentication and simple access controls. The customer is most concerned about wireless security, but also wants to ensure that only trusted users connect on the wire. However, the customer also wants all wired traffic to be forwarded locally on access layer switches. The customer already has a third-party firewall that protects the data center.
The customer wants to use certificates to authenticate user devices, but is concerned about the complexity of deploying the solution. The architect should recommend a way to simplify. For the most part users connect company-issued laptops to the network. However, users can bring their own devices and connect them to the network. The customer does not know how many devices each user will connect, but expects about two or three per-user. DHCP logs indicate that the network supports a maximum of 2800 devices.
Refer to the provided scenario.
Which solution should the architect recommend on the 2930M switches to authenticate and control wired employee devices?

An architect plans to purpose two Aruba Mobility Controllers (MCs) in a cluster. The customer has a large
building that needs to support about 10,000 devices. The architect plans to associate the Employees WLAN
with VLAN ID 10.
What is one Aruba best practice for this design?
