H12-261_V3.0-ENU Exam Question 21

In an MPLS VPN network, when a data packet enters the public and is forwarded, it will be encapsulated with two layers of MPLS labels. Which of the following options describes the processing procedure of the data packet correctly? (Multiple Choice)

A.The Egress PE device correctly sends the data packet to the corresponding VPN according to the inner label

B.The packet is forwarded to the Egress PE device after the outer label pops up on the penultimate hop device

C.The Egress PE device receives untagged IP packets

D.The outer label of the packet received by the penultimate hop device is 3

H12-261_V3.0-ENU Exam Question 22

As shown in the following figure, what routes can R2 learn?

A.R2 can learn all the routes of R1.

B.R2 can learn the route 10.1.1.0/24.

C.R2 can learn routes 10.1.2.0/24 and 10.1.3.0/24.

D.R2 can learn the LSPs of R1 but cannot add them to the routing table.

H12-261_V3.0-ENU Exam Question 23

When BGP EVPN Type2 routing is used to transmit IRB type routing, what does the information carried include? (Multiple choice)

A.Three-tier VNI

B.Host MAC address

C.Layer 2 VNI

D.Host IP address

H12-261_V3.0-ENU Exam Question 24

Which of the following statements about static VXLAN channel configuration are correct? (Multiple choice)

A.In the NVE interface, the destination address of the VXLAN tunnel can be specified by the address in the head-end copy list. Multiple VXLAN tunnels can only create one NVE interface

B.A BD needs to create an NVE interface, when there are multiple BDs, multiple NVE interfaces must be created

C.For a VXLAN tunnel, a one-to-one corresponding NVE interface needs to be created, in which the source IP address and destination IP address are clearly specified. Therefore, there are multiple VXLAN tunnels on VTEP. The corresponding number of NVE interfaces must be configured

D.One NVE interface can be associated with multiple VNIs, so when there are multiple BDs, only one NVE interface can be created

H12-261_V3.0-ENU Exam Question 25

Which scenario can use AS-path -filter?

A.Filter the route received to the BGP neighbor according to the AS_PATH attribute carried in the route. For example, the command peer x.x.x.x as-path-filter import

B.apply clause in Route-policy

C.Filter the route sent to the BGP neighbor according to the AS_PATH attribute carried in the route. For example, the command peer x.x.x.x as-path-filter export

D.If-match clause in Route-policy
