Online Access Free Nokia.4A0-116.v2023-05-04.q17 Practice Test (Page 3)

4A0-116 Exam Question 6

Based on the exhibit, and given that the system IP address of router RIO is 10.10.10.10, which of the following statements is FALSE?

A.The underlying routing protocol being used in the network for segment routing is IS-IS.

B.Router Rl participates in at least two flex-algo instances.

C.Router RIO participates in flex-algo instance 130.

D.The Node-SID assigned to router RIO for flex-algo instance 129 is 524338.

4A0-116 Exam Question 7

Which of the following statements about a Segment Routing SID is FALSE?

A.A Node-SID is usually associated with a router's system interface.

B.A Prefix-SID can be configured directly as a label value or indirectly as an index.

C.Adjacency-SID values are taken from the SRGB configured for the routing protocol.

D.An Adjacency-SID does not have to be configured.

4A0-116 Exam Question 8

The exhibit presents packets being transmitted inside an LSP's multi-segment primary path going from router R1 to router R8. The LSP also has a standby secondary path, and Seamless-BFD has been enabled on the primary path. The link between routers R1 and R2 fails, and fast re-route (FRR) is triggered. As a result, router R1 forwards the packets to router R3 and adds the proper FRR encapsulation to reach which router?

A.To reach router R8, which is the tail-end of the LSP.

B.To reach router R2, which is the LSP's intended next-hop.

C.To reach router R5, which is the shortest way to go back to the original path.

D.To reach router R4, which is the tail-end of the active segment.

4A0-116 Exam Question 9

Which of the following is NOT one of the main goals of traffic engineering?

A.Using the shortest possible path through the network to the destination.

B.Defining traffic paths based on various constraints.

C.Avoiding potential congestion points in the network.

D.Utilizing redundant links.

4A0-116 Exam Question 10

Which of the following statements about the operation of seamless-BFD is FALSE?

A.Seamless-BFD responses are sent back using the LSP label stack.

B.To be able to respond to seamless-BFD messages, a router must be configured as a reflector.

C.A seamless-BFD template needs to be configured on the head-end of the LSP.

D.The routing protocol (OSPF or IS-IS) is used to carry the reflector discriminator information.
