Online Access Free DES-4421 Exam Questions

What item is used to refer to a daisy-chained configuration of a multiple MX7000 chassis environment?

• A.Identity group
• B.Wired group
• C.Physical group
• D.Chassis group

An MX7000 administrator has been tasked to create a Scalable Fabric Architecture on a 3 chassis setup using Fabric B.
Which IOM configuration is recommended?

• A.Chassis 1 - Slot B1: MX7116n; Slot B2: MX7116nChassis 2 - Slot B1: MX7116n; Slot B2:
  MX7116nChassis 3 - Slot B1: MX9116n; Slot B2: MX9116n
• B.Chassis 1 - Slot B1: MX9116n; Slot B2: MX7116nChassis 2 - Slot B1: MX7116n; Slot B2:
  MX9116nChassis 3 - Slot B1: MX7116n; Slot B2: MX7116n
• C.Chassis 1 - Slot B1: MX9116n; Slot B2: MX5108nChassis 2 - Slot B1: MX5108n; Slot B2:
  MX9116nChassis 3 - Slot B1: MX5108n; Slot B2: MX5108n
• D.Chassis 1 - Slot B1: MX9116n; Slot B2: MX9116nChassis 2 - Slot B1: MX5108n; Slot B2:
  MX5108nChassis 3 - Slot B1: MX5108n; Slot B2: MX5108n

An MX7000 administrator has been tasked to perform the initial configuration of a new MX platform. The MX700 has seven MX740c, one MX5016s, two Management Modules (MMs), an LED-Only control panel, two MX9116n in Fabric A, two MX5108n in Fabric B, and two MX5000s in Fabric C.
What is a valid method to perform the initial MX platform configuration?

• A.Use KVM and racadm setniccfg command from MM configuration menu
• B.Use QuickSync 2
• C.Use Ethernet front panel port default DHCP address
• D.Use a serial DB9 / DB cable

What is a characteristic of MX7000 networking in Scalable Fabric Mode?

• A.Layer 2 bridging is disabled be default and interfaces must join a bridge domain (VLAN) before being to forward frames.
• B.Available on MX9116n FSE and MX7116n FEM but not on the MX5108n.
• C.Enabled by default, all switch-specific OS10EE capabilities are available.
• D.All switch interfaces are assigned to VLAN 1 by default and are in the same Layer 2 bridge domain.

In the assigned mapping of the MX5016s storage sled what is an assignment option used for independent storage to be mapped to a compute sled?

• A.Enclosure-assigned enables the MXG610s to the first eight drives in the MX5016s.
• B.Drive-assigned enables the MXG610s to the first eight drives in the MX5016s.
• C.Enclosure-assigned enables the MX5016 to be split among multiple compute sleds. Each compute node only "sees" the disks that are assigned to it and not the others.
• D.Drive-assigned enables the MX5016s to be split among multiple compute sleds. Each compute node only "sees" the disks that are assigned to it and not the others.
