A Synergy Integrator is configuring an HPE Synergy environment with two HPE Connect 40Gb F8 modules.
The Synergy integrator has four 40Gb uplinks connected to two upstream switches and needs all compute modules to share the full 160Gb of available bandwidth. The upstream are interconnected in a virtual port channel (vPC) pair.
What should the integrator do to ensure that the switch configuration doe not result in a network loop?

• A.Cross connect the Virtual Connect modules to the upstream switches and select all four 40Gb ports for the uplink Configure spanning tree protocol (STP) on the Virtual Connect uplink to default to port forward mode.
• B.Cross Connect the Volume Connect modules to the upstream switch and select all four 40Gb ports for the uplink Virtual Connect will automatically configure the Multiple Link Aggregation Group.
  (MLAG).
• C.Create two separate Virtual Connect uplinks Select two ports from each module fro each uplink.
  Configure spanning three protocol (STP) on both Virtual Connect uplinks to default port forward mode.
• D.Create two separate Virtual Connect uplinks. Select one part from each module for each uplink. Use two separate Logical Interconnect Group (LIGs) to keep the uplinks from looping.

How should a synergy integrator configure an HPE Synergy solution to provide shared storage to all compute nodes in a single frame?

• A.Import s Stresses SPAR system Composer and configure the server profiles to include SAN storage.
• B.Import a Linux based NFS into Composer and configure the server profile to include SAN storage.
• C.Use composer to configure the p55420 smart array controllers to HBA mode and configure the server profile to include SAN storage.
• D.Use Composer to configure a HPE Synergy D3940 storage and configure the server profiles to include SAN storage.

A customer is planning an HPE Synergy solution with 20 frames an needs to minimize the number of management ports that are required to connect the frames into the existing management network.
Which procedure should the Synergy into a integrator use to address the customer's concern?

• A.Connect FLMs from all frames into a management ring: Then connect the management ring to the customer's management network using two uplinks.
• B.Connect FLMs from all frames to two external switches for redundancy: Then connect the two uplinks from the two switches into the customer management network.
• C.Connect the RJ-45 front port of each frame to two external switches for redundancy: Then connect the uplink from the two switches into the customer's management network.
• D.Connect the RJ-45 front ports of each frame to an external switch. Then connect the uplink from the external switch into the customer management network.

A customer has the following requirements for an HPE Synergy solution:
* Data for the internal application needs to be stored in the frame.
* Compute modules needs to have access to a large database on an external storage array.
* The Synergy infrastructure should be managed with HPE OneView

• A.Two SAS Connection Modules into 1 and 2: two Synergy 40Gb Fb switch module into bays 3 and 4 two Brocade 16Gb/12 Fiber Channel switches into bays 5 and 6
• B.two SAS Connection Modules into bays 1 and 4, two HPE Synergy Connect SE modules into bays 3 and
  6
• C.two SAS Connection Modules into bays 1 and 2: two HPE Synergy Connect SE 40Gb F8 modules into bays and 4
• D.two SAS Connection Modules into bays 1 and 4: 4 two Synergy 40Gb F8 switch modules into 2 and 5:
  two Brocade 16Gb/12 FC Switches into bays 3 and 6

Refer to the exhibit.

A customer has an HPE Synergy 2-frame configuration, as shown. The customer has a new project and needs to increase the number of compute modules.
What is the maximum number of compute nodes that the customer's fabric could support?

• A.36
• B.24
• C.48
• D.60
