Online Access Free HPE2-Z39 Exam Questions

A network administrator needs to configure Virtual Switching Framework (VSF) for the first time on an ArubaOS switch. The administrator enters this command:

The administrator then wants to provision member 2 settings.
What must the administrator do before provisioning these settings?

• A.Configure SNMP settings that match settings configured on member 2
• B.Specify the model type for member 1.
• C.Join member 2 to the VSF fabric.
• D.Enable VSF on the switch and reboot.

The ArubaOS switches were at default settings.
The network administrator configures the VLANs and IP addresses as shown in the exhibit.
All inter switch links are untagged for VLAN 1 and tagged for VLANs 11 and 12.
There is no additional configuration performed on the switches.
The Windows Server and Windows Client are configured to use Switch-1 as their default gateway.
How does this configuration affect the network topology?

• A.The Windows Server and Windows Client can successfully ping each other.
• B.The Windows Server and Windows Client cannot ping each other; the VLANs are tagged incorrectly on one or more ports.
• C.The Windows Server and Windows Client cannot ping each other; IP routing must be enabled on all switches in the topology.
• D.The Windows Server and Windows Client cannot ping each other; IP routing must be enabled on Switch-1.

A network administrator enters this command on an ArubaOS switch:
Switch(config) # trunk 1,2 trk1
What is required for the switch to combine both interfaces in a link aggregation?

• A.that the interfaces are up and connect to interfaces that support active mode LACP
• B.that the interfaces are up
• C.that the interfaces are up and have LACP enabled on them
• D.that the interfaces are aggregated while in a shutdown state

Based on this ArubaOS switch output, what can a network administrator determine about the spanning tree topology?

• A.Port 3 will become the root port if the current root port becomes unavailable.
• B.Trk1 offers the lowest cost path to the common spanning tree root.
• C.Switch-C is the root bridge of the topology.
• D.Port 2 is an edge port

Refer to the exhibit.

What does the command output in the exhibit indicate about the status of an Aruba Virtual Switching Framework (VSF) fabric?

• A.The second member of the VSF fabric has not yet joined the fabric, so LLDP-MAD is not operational.
• B.The two members of the VSF fabric cannot contact each other, and the other member is the active member.
• C.The two members of the VSF fabric cannot contact each other, and this member is the active member.
• D.The two members of the VSF fabric are currently connected.
