A customer requires APs that meet these minimal criteria:
* Support for MU-MIMO
* Support for up to four spatial streams, both when MU-MIMO is used and when it is not used
* Support for transmissions to up to three MU-MIMO clients at the same time
The architect finds these specifications for the two models under consideration:
AP-335 = 4x4:4:4:4:3
AP-325 = 4x4:4:4:3:3
What should the architect determine from these specifications?

Refer to the exhibits.
Exhibit 1 shows the logical plan, and Exhibit 2 shows the BOM created with IRIS. An architect plans to propose two 5406Rzl switches as a VSF fabric for a campus network core. Which issue with the plan should the architect correct?
Exhibit 1

Exhibit 2

Refer to the exhibit.

An architect selects 5406R switches for the aggregation layer. What is an appropriate amount of bandwidth for the link aggregation between each aggregation layer VSF fabric and the campus core?

The customer has an office environment with users who have laptops that can connect with wired or wireless.
Users also bring one or two of their own devices. An architect creates a proposal with Aruba AP-325s, 7210 Mobility Controllers (MCs), a Mobility Master (MM), and Aruba 2930M switches at the access layer to support the laptops and APs.
The architect plans to recommend 802.1X authentication without tunneled node on Aruba 2930M switch ports that connect to laptops. What is one advantage of this form of authentication?

Read this scenario thoroughly, and then answer each question that displays on the right side of the screen.
An architect proposes these products for a customer who wants a wireless and wired upgrade:
* Aruba 2930M switches at the access layer
* Aruba 5406R switches at the core
* Aruba AP-325s
* Aruba 7205 Mobility Controllers (MCs), deployed in a cluster
* Aruba Mobility Master (MM)
* Aruba ClearPass Cx000V
* Aruba AirWare
The architect also needs to propose a security plan for the solution. The customer has 900 employees and up to
30 guests a day. The customer wants to protect the internal perimeter of the network with authentication and
simple access controls. The customer is most concerned about wireless security, but also wants to ensure that
only trusted users connect on the wire. However, the customer also wants all wired traffic to be forwarded
locally on access layer switches. The customer already has a third-party firewall that protects the data center.
The customer wants to use certificates to authenticate user devices, but is concerned about the complexity of
deploying the solution. The architect should recommend a way to simplify. For the most part users connect
company-issued laptops to the network. However, users can bring their own devices and connect them to the
network. The customer does not know how many devices each user will connect, but expects about two or
three per-user. DHCP logs indicate that the network supports a maximum of 2800 devices.
Refer to the provided scenario. Based on the plan for wired authentication, what is a correct plan for wired
user VLANs?
