Refer to the scenario.
A customer requires these rights for clients in the "medical-mobile" AOS firewall role on Aruba Mobility Controllers (MCs):
Permitted to receive IP addresses with DHCP
* Permitted access to DNS services from 10.8.9.7 and no other server
* Permitted access to all subnets in the 10.1.0.0/16 range except denied access to 10.1.12.0/22
* Denied access to other 10.0.0.0/8 subnets
* Permitted access to the Internet
* Denied access to the WLAN for a period of time if they send any SSH traffic
* Denied access to the WLAN for a period of time if they send any Telnet traffic
* Denied access to all high-risk websites
External devices should not be permitted to initiate sessions with "medical-mobile" clients, only send return traffic.
The exhibits below show the configuration for the role.

There are multiple issues with the configuration.
What is one of the changes that you must make to the policies to meet the scenario requirements? (In the options, rules in a policy are referenced from top to bottom. For example, "medical-mobile" rule 1 is "ipv4 any any svc-dhcp permit," and rule 8 is "ipv4 any any any permit'.)

• A.In the "medical-mobile" policy, move rules 6 and 7 to the top of the list.
• B.Move the rule in the "apprf-medical-mobile-sacl" policy between rules 7 and 8 in the "medical-mobile" policy.
• C.In the "medical-mobile" policy, change the subnet mask in rule 3 to 255.255.248.0.
• D.In the "medical-mobile" policy, change the source in rule 1 to "user."

Refer to the exhibit.

Aruba ClearPass Policy Manager (CPPM) is using the settings shown in the exhibit. You reference the tag shown in the exhibit in enforcement policies related to NASes of several types, including Aruba APs, Aruba gateways, and AOS-CX switches.
What should you do to ensure that clients are reclassified and receive the correct treatment based on the tag?

• A.Enable profiling in each service using one of these enforcement profiles. Set the profiling action to the correct one for the NASes using that service.
• B.Set the Tags Update Action to No Action. Then instead enable the RADIUS CoAs using enforcement profiles in the rules that match clients with the tag shown in the exhibit.
• C.Change the RADIUS action to [Aruba Wireless -Terminate Session] which is supported by all the NASes in question.
• D.Change the RADIUS action to [Aruba Wireless - Bounce Switch Port] which is supported by all the NASes in question.

You are working with a developer to design a custom NAE script for a customer. The NAE agent should trigger an alert when ARP inspection drops packets on a VLAN. The customer wants the admins to be able to select the correct VLAN ID for the agent to monitor when they create the agent.
What should you tell the developer to do?

• A.Use this variable, %{vlan-id} when defining the monitor URI in the NAE agent script.
• B.Use a callback action to collect the ID of the VLAN on which admins have enabled NAE monitoring.
• C.Define a VLAN ID parameter; reference that parameter when defining the monitor URI.
• D.Create multiple monitors within the script from which admins can select when they create the agent.

Refer to the scenario.
# Introduction to the customer
You are helping a company add Aruba ClearPass to their network, which uses Aruba network infrastructure devices.
The company currently has a Windows domain and Windows CA. The Window CA issues certificates to domain computers, domain users, and servers such as domain controllers. An example of a certificate issued by the Windows CA is shown here.


The company is in the process of adding Microsoft Endpoint Manager (Intune) to manage its mobile clients.
The customer is maintaining the on-prem AD for now and uses Azure AD Connect to sync with Azure AD.
# Requirements for issuing certificates to mobile clients
The company wants to use ClearPass Onboard to deploy certificates automatically to mobile clients enrolled in Intune. During this process, Onboard should communicate with Azure AD to validate the clients. High availability should also be provided for this scenario; in other words, clients should be able to get certificates from Subscriber 2 if Subscriber 1 is down.
The Intune admins intend to create certificate profiles that include a UPN SAN with the UPN of the user who enrolled the device.
# Requirements for authenticating clients
The customer requires all types of clients to connect and authenticate on the same corporate SSID.
The company wants CPPM to use these authentication methods:
* EAP-TLS to authenticate users on mobile clients registered in Intune
* TEAR, with EAP-TLS as the inner method to authenticate Windows domain computers and the users on them To succeed, EAP-TLS (standalone or as a TEAP method) clients must meet these requirements:
Their certificate is valid and is not revoked, as validated by OCSP
The client's username matches an account in AD
# Requirements for assigning clients to roles
After authentication, the customer wants the CPPM to assign clients to ClearPass roles based on the following rules:
* Clients with certificates issued by Onboard are assigned the "mobile-onboarded" role
* Clients that have passed TEAP Method 1 are assigned the "domain-computer" role Clients in the AD group "Medical" are assigned the "medical-staff" role Clients in the AD group "Reception" are assigned to the "reception-staff" role The customer requires CPPM to assign authenticated clients to AOS firewall roles as follows:
* Assign medical staff on mobile-onboarded clients to the "medical-mobile" firewall role
* Assign other mobile-onboarded clients to the "mobile-other" firewall role
* Assign medical staff on domain computers to the "medical-domain" firewall role
* All reception staff on domain computers to the "reception-domain" firewall role
* All domain computers with no valid user logged in to the "computer-only" firewall role
* Deny other clients' access
# Other requirements
Communications between ClearPass servers and on-prem AD domain controllers must be encrypted.
# Network topology
For the network infrastructure, this customer has Aruba APs and Aruba gateways, which are managed by Central. APs use tunneled WLANs, which tunnel traffic to the gateway cluster. The customer also has AOS-CX switches that are not managed by Central at this point.

# ClearPass cluster IP addressing and hostnames
A customer's ClearPass cluster has these IP addresses:
* Publisher = 10.47.47.5
* Subscriber 1 = 10.47.47.6
* Subscriber 2 = 10.47.47.7
* Virtual IP with Subscriber 1 and Subscriber 2 = 10.47.47.8
The customer's DNS server has these entries
* cp.acnsxtest.com = 10.47.47.5
* cps1.acnsxtest.com = 10.47.47.6
* cps2.acnsxtest.com = 10.47.47.7
* radius.acnsxtest.com = 10.47.47.8
* onboard.acnsxtest.com = 10.47.47.8
You have created a role mapping policy as shown in the exhibits below.

What is one change that you need to make to this policy?

• A.In rule 1 change Subject-CN to Issuer-CN.
• B.Move rules 2 and 3 to the top of the list.
• C.Change the default role to 'mobile-onboarded*
• D.Change the rules evaluation mechanism to first applicable.

Refer to the scenario.
A customer has an AOS10 architecture that is managed by Aruba Central. Aruba infrastructure devices authenticate clients to an Aruba ClearPass cluster.
In Aruba Central, you are examining network traffic flows on a wireless IoT device that is categorized as
"Raspberry Pi" clients. You see SSH traffic. You then check several more wireless IoT clients and see that they are sending SSH also.
You want a fast way to find a list of all the IoT clients that have used SSH.
What step can you take?

• A.Run a search for SSH traffic and loT client IDs in Aruba ClearPass Policy Manager's (CPPM's) accounting information.
• B.Use Central's Live Events monitoring tool to detect which clients meet the desired criteria.
• C.Create and apply a Central client profile tag that selects the SSH application and the clients' category.
• D.Use Central's Gateway IDS/IPS Security Dashboard to search for SSH events and sources.
