Online Access Free JN0-643 Exam Questions

You are troubleshooting an LLDP neighbor and cannot see the IP address of the neighboring EX Series switch.
What is causing the problem?

• A.IP addresses are not sent in any LLDP TLVs.
• B.You must enable LLDP-ME
• C.A VLAN interface must be configured under the [edit vlans] hierarchy.
• D.A management address must be configured under the [edit protocols lldp] hierarchy.

An OSPF router is an ABR but not an ASBR.
Which three types of LSAs would you expect this router to generate? (Choose three.)

• A.Type 1 LSA
• B.Type 4 LSA
• C.Type 3 LSA
• D.Type 6 LSA
• E.Type 5 LSA

-- Exhibit -

-- Exhibit --
Click the Exhibit button.
You are the administrator for the network shown in the exhibit. R1 receives the
1 96.15.4.0/24 route from routers R2, R3, and R4. Local preference values have not been modified in this network. You are asked to ensure that R1 prefers the path through AS
3 149 for traffic destined to 196.15.4.0/24.
Which two methods will accomplish this task? (Choose two.)

• A.Configure as-path-prepend on R2 and R4.
• B.Configure always-compare-med on R1.
• C.Configure local-as on R3.
• D.Configure a lower local preference on R3.

R1 and R2 are ASBRs in the same area, each with an equal cost external path to the same external network prefix. R1 advertises an external route into OSPF with a Type 1 metric.
R2 advertises an external route into OSPF with a Type 2 metric.
Which route would be preferred?

• A.R2's route is preferred because Type 2 metrics take into account the internal and external cost.
• B.R1's route is preferred because Type 1 metrics take into account the external cost only.
• C.R1's route is preferred because Type 1 metrics take into account the internal and external cost.
• D.R2's route is preferred because Type 2 metrics take into account the external cost only.

-- Exhibit -
-- Exhibit --
Click the Exhibit button.
Referring to the exhibit and based on the output below from Sw-1 and Sw-2, which statement is true?
Sw-1> show spanning-tree mstp configuration
MSTP information
Context identifier : 0
Region name : juniper
Revision : 1
Configuration digest : 0x9357ebb7a8d74dd5fef4f2bab50531aa
MSTI Member VLANs
0 0-9,11-19,21-4094
1 10
2 20
Sw-2# run show spanning-tree mstp configuration
MSTP information
Context identifier : 0
Region name : juniper
Revision : 1
Configuration digest : 0x387b5f2ea2394b14e091f0921ee7b9a8
MSTI Member VLANs
0 0-9,11-14,16-19,21-4094
1 10,15
2 20

• A.There will be only one MSTI 2 root bridge.
• B.There will be only one CST root bridge.
• C.There will be only one CIST root bridge.
• D.Sw-1 and Sw-2 are in different MSTP regions.
