Online Access Free JN0-683 Exam Questions

Click the Exhibit button. Both DC and DC2 are using EVPN-VXLAN technology deployed using an ERB architecture. A server on the Red VLAN must communicate with a server on the Green VLAN. The Blue VLAN in DC and DC2 needs to be the same VLAN.
Which statement is correct?

• A.A lean super spine device must be added to DC and DC2; all VLANs must be stretched to the lean super spine device and the lean super spine devices must stitch all the VLANs together.
• B.An interconnect is required between the four SRX Series devices; the Blue VLAN must be stretched and a transit VNI must be added for the Red and Green VLANs.
• C.An interconnect is required between four leaf devices in the services blocks; the Red VLAN and the Green VLAN must be stitched and the Blue VLAN must be stretched.
• D.The eight spine devices must be configured as border spine devices; a full mush interconnect must exist between all eight spine devices and the Blue VLAN must be stitched together

An IP fabric with EBGP configured in the overlay uses a different AS number for each node in the fabric.
Which two benefits does this configuration have over using a single AS scheme? (Choose two.)

• A.It avoids the use of route reflectors.
• B.There is more TCAM space for AS numbers.
• C.There are fewer BGP peers.
• D.It provides more efficient BGP path selection.

You are deploying a new network to support your AI workloads on devices that support at least
400 Gbps Ethernet. There is no requirement for any Layer 2 VLANs in this network.
Which network architecture would satisfy this requirement?

• A.an IP fabric with an EVPN-VXLAN architecture
• B.an IP fabric using PIM-SM to signal VXLAN overlay
• C.an IP fabric using the EVPN-MPLS architecture
• D.an IP fabric using EBGP

A local VTEP has two ECMP paths to a remote VTEP.
Which two statements are correct when load balancing is enabled in this scenario? (Choose two.)

• A.The destination port in the UDP header is used to load balance VXLAN traffic.
• B.The inner packet fields are not used in the hash for load balancing.
• C.The inner packet fields are used in the hash for load balancing.
• D.The source port in the UDP header is used to load balance VXLAN traffic.

You are using a single tenant data center with a bridged overlay architecture. In this scenario, how do hosts of the different virtual networks communicate with each other?

• A.using anycast gateway addresses configured on the leaf devices
• B.using virtual gateway addresses configured on the spine
• C.off-fabric using an external device
• D.using EVPN Type 5 routes
