You have a server named Server1 that runs Windows Server 2016.
You need to deploy the first cluster node of a Network Controller cluster.
Which four cmdlets should you run in sequence? To answer, move the appropriate cmdlets from the list of cmdlets to the answer area and arrange them in the correct order.

Correct Answer:

Explanation

Deploy Network Controller using Windows PowerShell
Step 1: Install-WindowsFeature
Install the Network Controller server role
To install Network Controller by using Windows PowerShell, type the following commands at a Windows PowerShell prompt, and then press ENTER.
Install-WindowsFeature -Name NetworkController -IncludeManagementTools
Step 2: New-NetworkControllerNodeObject
You can create a Network Controller cluster by creating a node object andthen configuring the cluster.
You need to create a node object for each computer or VM that is a member of the Network Controller cluster.
Tocreate a node object, type the following command at the Windows PowerShell command prompt, and then press ENTER. Ensure that you add values for each parameter that are appropriate for your deployment.
New-NetworkControllerNodeObject -Name <string> -Server<String> -FaultDomain <string>-RestInte Step 3: Install-NetworkControllerCluster To configure the cluster, typethe following command at the Windows PowerShell command prompt, and then press ENTER. Ensure that you add values for each parameter that are appropriate for your deployment.
Install-NetworkControllerCluster -Node <NetworkControllerNode[]> -ClusterAuthentication ...
Step 4: Install-NetworkController
To configure the Network Controller application, type the following command at the Windows PowerShell command prompt, and then press ENTER. Ensure that you add values for each parameter that are appropriate for your deployment.
Install-NetworkController -Node <NetworkControllerNode[]> -ClientAuthentication References: https://technet.microsoft.com/en-us/library/mt282165.aspx

Your network contains an Active Directory domain named contoso.com. The domain contains two servers named Server1 and Server2 that run Windows Server 2016.
Server1 has IP Address Management (IPAM) installed. Server2 has Microsoft System Center 2016 Virtual Machine Manager (VMM) installed.
You need to integrate IPAM and VMM.
Which types of objects should you create on each server? To answer, drag the appropriate object types to the correct servers. Each object type may be used once, more than once, or not at all. You may need to drag the split bar between panes or scroll to view content.

Correct Answer:

Explanation

Server 1 (IPAM): Access Policy
VMM must be granted permission to view and modify IP address space in IPAM, and to perform remote management of the IPAM server. VMM uses a "Run As" account to provide these permissions to the IPAM network service plugin. The "Run As" account must be configured with appropriate permission on the IPAM server.
To assign permissions to the VMM user account
In the IPAM server console, in the upper navigation pane, click ACCESS CONTROL, right-click Access Policies in the lower navigation pane, and then click Add AccessPolicy.
Etc.
Server 2 (VMM) #1: Network Service
Server 2 (VMM) #2: Run As Account
Perform the following procedure using the System Center VMM console.
To configure VMM (see step 1-3, step 6-7)

Etc.
References: https://technet.microsoft.com/en-us/library/dn783349(v=ws.11).aspx

You are implementing a new network. The network contains a DHCP server named DHCP1 that runs Windows Server 2016. DHCP1 contains a scope named Scope1 for the 192.168.0/24 subnet.
Your company has the following policy for allocating IP addresses:
* All server addresses must be excluded from DHCP scopes.
* All client computer must receive IP addresses from Scope1.
* All Windows servers must have IP addresses in the range of 192.168.0.200 to 192.168.0.240
* All other network devices must have IP addresses in the range of 192.168.0.180 to 192.168.0.199.
You deploy a print device named Print1.
You need to ensure that Print1 adheres to the policy for allocating IP addresses.
Which command should you use?

• A.Add-DhcpServerv4Lease
• B.Add-DhcpServerv4ExclusionRange
• C.Add-DhcpServerv4Reservation
• D.Add-DhcpServerv4Filter

You are planning the deployment of DNS to a new network.
You have three internal DNS servers configured as shown in the following table.

The conIoso.com zone contains zone delegations for east.contcso.com and wesLcontoso.com. All the DNS servers use root hints. You need to ensure that all the DNS servers can resolve the names of all the internal namespaces and internet hosts. Solution: On Server2 and Server3. you configure a conditional forwarder for contoso.com. Does the meet the goal?

• A.Yes
• B.No

You need to implement network virtualization.
On which object should you configure the virtual subnet ID?

• A.Virtual network adapter
• B.Virtual switch
• C.Hyper-V server
• D.VM
