In system modeling, what does a Package Diagram focus on?
Response:

• A.The dynamic behavior of a system in terms of states and transitions
• B.The internal structure and collaborations between parts within a system
• C.The allocation of software components to hardware nodes
• D.The hierarchical decomposition of a system into subsystems or modules

Is this diagram the correct representation of the requirements listed below?

Response:

• A.Yes
• B.Yes but it is incomplete
• C.No

In system behavior modeling, what does a Timing Diagram focus on?
Response:

• A.The dynamic behavior of a system in terms of states and transitions
• B.To illustrate the interactions between actors and the system over time
• C.The allocation of software components to hardware nodes
• D.To specify the sequence of messages between system components

A Value property can represent a...
Response:

• A.String
• B.Float
• C.Boolean

In SysML, what is the purpose of an Activity Diagram?
Response:

• A.To describe the dynamic behavior of a system in terms of activities and their dependencies
• B.To model the flow of control between system components
• C.To show the state transitions of an object over time
• D.To represent the structure of a system using blocks and relationships
