When receiving an XML document following the schema defined by TravelXML (portions modified for this question), the document is processed via SAX programming. Push the Exhibit Button to load the referenced "XML Schema".
When processing the following "XML Document" according to the method shown by "SAX
Processing," which of the following correctly describes the output results (print method output)?
[XML Document]
The root element name (document element name) is "BookingNotification".
The XML document follows the "XML Schema" definition.
There is no DTD for the XML Document.
The XML Document is comprised of elements and character data; comments and CDATA sections, etc. are not included.
The XML Document is indented, and includes ignorable white spaces such as line feeds and tabs before the start-tags.
[SAX Processing]
Use the following "ContentHandlerImpl" class, and parse the XML Document using SAX.
The SAX parser is namespace aware.
Assume no execution errors.}

• A.All character data of elements can be output, and ignorable white spaces are also output
• B.A portion of character data of elements cannot be output
• C.All character data of elements can be output, ignorable white spaces are not output
• D.No character data of elements can be output

Select which of the following correctly describes the message reception processing circumstances when a well-formed XML document has been sent/ received. [Transmission] Character encoding for the transmitted XML document is "UTF-16", and no XML declaration has been specified. The media type for transmission is set as "text/xml" without charset parameter. [Receipt] Implementation follows RFC3023 and XML 1.0. The receiving system first identifies the media type, and then processes the XML document. At the point that character encoding has been determined, an XML declaration (including encoding declaration) is appended automatically to the head of the received XML document.

• A.The character encoding is identified from the XML Document binary. An XML declaration (<?xml version="1.0" encoding="UTF-16"?>) is appended accordingly
• B.The media type identification appends <?xml version="1.0" encoding="UTF-8"?>, at which point the XML processor throws an error when processing the XML document
• C.The media type identification appends <?xml version="1.0" encoding="us-ascii"?>, at which point the XML processor throws an error when processing the XML document
• D.Character encoding is determined by the system locale. Since the XML declaration is appended accordingly, in certain cases the XML processor will throw an error when processing the XML document

Push the Exhibit Button to load the referenced "XML Document". When processing the "XML Document" according to the method shown by "DOM Processing," which of the following is the most appropriate expression of the results under XML 1.0? Line feeds and/or indents are not reflected in the results.
Although the expected processing result is choice "B", processing may not occur as expected.
[DOM Processing]
Process XML using the following method.
Document output = createXML( doc, impl );
The variable doc here references the Document instance of the loaded XML Document.
The variable impl here references the DOMImplementation instance.
The DOM parser is namespace aware.
Assume no execution errors.
}
return output;
}

• A.<VisitList xmlns="urn:xmlmaster:NEWLIST">
  <Visit>
  <Date xmlns="urn:xmlmaster:LIST">2004-07-01</Date>
  <Worker xmlns="urn:xmlmaster:WORKER" Name="Jeff Workman"/>
  <Activity xmlns="urn:xmlmaster:VISIT" Code="0001">
  <DateTime>2004-07-01 09:00</DateTime>
  <Job Procedure="Install freezer" Time="2"/>
  <Status>COMPLETED</Status>
  </Activity>
  </Visit>
  </VisitList>
• B.<VisitList xmlns="urn:xmlmaster:NEWLIST">
  <Visit>
  <Worker xmlns="urn:xmlmaster:WORKER" Name="Jeff Workman"/>
  <Activity xmlns="urn:xmlmaster:VISIT" Code="0001">
  <DateTime>2004-07-01 09:00</DateTime>
  <Job Procedure="Install freezer" Time="2"/>
  <Status>COMPLETED</Status>
  </Activity>
  </Visit>
  </VisitList>
• C.<VisitList xmlns="urn:xmlmaster:NEWLIST">
  <Visit>
  <Date xmlns="urn:xmlmaster:LIST">2004-07-01</Date>
  <Worker xmlns="urn:xmlmaster:WORKER" Name="Jeff Workman"/>
  <Activity xmlns="urn:xmlmaster:VISIT" Code="0001">
  <DateTime>2004-07-01 09:00</DateTime>
  <Job Procedure="Install freezer" Time="2"/>
  <Status>COMPLETED</Status>
  </Activity>
  <Activity xmlns="urn:xmlmaster:VISIT" Code="0002">
  <DateTime>2004-07-01 13:00</DateTime>
  <Job Procedure="Install air conditioner" Time="2"/>
  <Status>WAITING</Status>
  </Activity>
  <Visit>
  </VisitList>
• D.<VisitList xmlns="urn:xmlmaster:NEWLIST">
  <Visit>
  <Worker xmlns="urn:xmlmaster:WORKER" Name="Jeff Workman"/>
  <Activity xmlns="urn:xmlmaster:VISIT" Code="0001">
  <DateTime>2004-07-01 09:00</DateTime>
  <Job Procedure="Install freezer" Time="2"/>
  <Status>COMPLETED</Status>
  </Activity>
  <Activity xmlns="urn:xmlmaster:VISIT" Code="0002">
  <DateTime>2004-07-01 13:00</DateTime>
  <Job Procedure="Install air conditioner" Time="2"/>
  <Status>WAITING</Status>
  </Activity>
  </Visit>
  </VisitList>

Which of the following is incorrect with respect to general characteristics of DOM (Level 2) processing and data binding tool processing?

• A.A validation against the schema cannot be performed with the DOM; however, a data binding tool can be used to peform a validation against the schema
• B.A DOM parser cannot be used to execute a program created to use a different DOM parser; however, a data binding tool can be used to execute a program created to use a different data binding tool
• C.For a compiled programming language, compared to DOM processing, a data binding tool can detect more element name mistakes and other programming errors during compiling
• D.Data types such as integers and dates cannot be handled by DOM; however, a data binding tool can be used to handle the data type

Push the Exhibit Button to load the referenced "testml.xsd". Assume that "testml.xsd" is defined. Without rewriting this XML Schema Document ("testml.xsd"), create a new, separate XML Schema Document to partially change the schema definition replacing the phone element with a cellPhone element. As a result, the following "XML Document" will be valid against the new schema. Which of the following correctly describes the new XML Schema Document?
Assume that the XML parser correctly processes the XML Schema schemaLocation attribute.

• A.<xs:schema xmlns:xs="http://www.w3.org/2001/XMLSchema">
  <xs:import schemaLocation="testml.xsd" />
  <xs:element name="cellPhone" type="xs:string" />
  </xs:schema>
• B.<xs:schema xmlns:xs="http://www.w3.org/2001/XMLSchema">
  <xs:include schemaLocation="testml.xsd" />
  <xs:element name="cellPhone" substitutionGroup="phone" type="xs:string" />
  </xs:schema>
• C.It is not possible to implement a function of the type proposed.
• D.<xs:schema xmlns:xs="http://www.w3.org/2001/XMLSchema">
  <xs:redefine schemaLocation="testml.xsd">
  <xs:element name="cellPhone" base="phone" type="xs:string" />
  </xs:redefine>
  </xs:schema>
