In the PIM-DM networking, the comparison rules for Assert messages are as follows

The IP address of the host PCA is 40.1.1.1, and the MAC address is 0011.1111.1111. The PCA is connected to the GigabitEthernet1/0/1 port of the switch SWA. The following commands are configured on the switch SWA:
[SWA]vlan 10
[SWA-vlan10]quit
[SWA]vlan 20
[SWA-vlan20]protocol-vlan ipv4
[SWA-vlan20]quit
[SWA]vlan 30
[SWA-vlan30]quit
[SWA]mac-vlan mac-address 0011-1111-1111 vlan 30
[SWA]vlan 40
[SWA-vlan40]ip-subnet-vlan ip 40.1.1.0 255.255.255.0
[SWA-vlan40]quit
[SWA]interface GigabitEthernet 1/0/1
[SWA-GigabitEthernet1/0/1]port link-type hybrid
[SWA-GigabitEthernet1/0/1]port hybrid pvid vlan 10
[SWA-GigabitEthernet1/0/1]port hybrid vlan 10 20 30 40 untagged
[SWA-GigabitEthernet1/0/1]port hybrid protocol-vlan vlan 20 0
[SWA-GigabitEthernet1/0/1]port hybrid ip-subnet-vlan vlan 40
[SWA-GigabitEthernet1/0/1]mac-vlan enable
[SWA-GigabitEthernet1/0/1]vlan precedence ip-subnet-vlan
After the configuration is complete, it can be judged that PCA will join

In the switching network as shown in the figure, all three switches have only default VLAN1. The interconnection ports of the three switches are Trunks, and all VLANs are allowed to pass. All three switches have the global and port GVRP functions enabled. VLAN 10 is created on the switch SWA, VLAN 20 is created on the switch SWC, and the GVRP registration mode of the Ethernet1/0/1 port is set to Forbidden on the switch SWA. Check the status of each Trunk port on the three switches. (Choose one or more)

The Layer 3 switch receives the data frame and performs the Layer 2/Layer 3 forwarding judgment

The core goal of highly reliable redundant network design is
